Hot-rolled universal beams (UB) — structural steel I-beams for floors, roofs and primary building frames.
Universal beams (UB) — also called steel I-beams — are hot-rolled structural sections with wide flanges, used as the primary load-bearing members in floors, roofs and building frames. We supply the full range of universal beams from 150 UB to 610 UB in Grade 300 to AS/NZS 3679.1, with mill test certificates and full traceability. Cutting, drilling and surface treatment are available to suit your fabrication programme.
Product Range
Full Size Range
Universal beams from 150 UB 14.0 through to 610 UB 125 to suit spans and loads across building types.
Grade 300 Structural Steel
Hot-rolled to AS/NZS 3679.1 in Grade 300 with verified yield strength and weldability.
Steel Beam Sizes & Properties
Section dimensions, mass per metre and section properties available to support structural design and selection.
Cut, Drilled & Coped
Cutting to length, hole drilling and end preparation to your drawings at our partner facilities.
Surface Treatment
Shop primer, paint systems or hot-dip galvanising as specified for the service environment.
Universal Beam (UB) Sizes
Standard Australian universal beam designations to AS/NZS 3679.1 in Grade 300. The leading number is the nominal depth in millimetres; the trailing figure is the mass per metre.
| Designation | Depth (mm) | Flange width (mm) | Mass (kg/m) |
|---|---|---|---|
| 150 UB 14.0 | 150 | 75 | 14.0 |
| 180 UB 16.1 | 173 | 90 | 16.1 |
| 200 UB 25.4 | 203 | 133 | 25.4 |
| 250 UB 31.4 | 252 | 146 | 31.4 |
| 310 UB 40.4 | 304 | 165 | 40.4 |
| 360 UB 50.7 | 356 | 171 | 50.7 |
| 410 UB 53.7 | 403 | 178 | 53.7 |
| 460 UB 74.6 | 457 | 190 | 74.6 |
| 530 UB 92.4 | 533 | 209 | 92.4 |
| 610 UB 125 | 612 | 229 | 125 |
Additional sizes, grades, lengths and finishes available on request — contact us for a full size chart and quote.
Common Applications
- Primary building frames and floor beams
- Portal frames and industrial buildings
- Bridges and transport infrastructure
- Mezzanines and structural platforms
- Mining and resource processing structures
Relevant Standards
- AS/NZS 3679.1 — Hot-rolled structural steel bars and sections
- AS 4100 — Steel structures
- AS 5131 — Structural steelwork fabrication and erection
- AS/NZS 1554 — Structural steel welding
