SteelLintels
Galvanised steel lintels — angle and flat bar lintels to support masonry over door and window openings.
Steel lintels are hot-rolled angle or flat bar sections that support brickwork and masonry over door, window and other openings. We supply galvanised steel lintels across the full range of sizes for the cavity and opening width, manufactured to AS/NZS 3679.1 and hot-dip galvanised to AS/NZS 4680 for durability in masonry. Sizes are selected in line with AS 3700 masonry requirements, with material certification provided.
Product Range
Galvanised Angle Lintels
Hot-dip galvanised equal and unequal angle lintels for single-leaf and cavity masonry openings.
Flat Bar Lintels
Galvanised flat bar lintels for narrow openings and rendered or face-brick applications.
Sized to the Opening
Lintel size selected to suit the opening width, masonry load and cavity in line with AS 3700.
Hot-Dip Galvanised
Galvanised to AS/NZS 4680 for long-term durability and corrosion resistance within masonry.
Cut-to-Length
Lintels cut to the required length including end bearing for the opening.
Common Applications
- Door and window openings in brickwork
- Cavity and single-leaf masonry walls
- Garage and large openings
- Residential and commercial construction
- Renovation and extension work
Relevant Standards
- AS/NZS 3679.1 — Hot-rolled structural steel bars and sections
- AS/NZS 4680 — Hot-dip galvanized (zinc) coatings on fabricated ferrous articles
- AS 3700 — Masonry structures
- AS 4100 — Steel structures
Steel Lintels — Frequently Asked Questions
What steel lintels do you supply?
Galvanised angle lintels from 90 × 90 to 150 × 100 mm and flat bar lintels, plus fabricated T-bar lintels for cavity brickwork, all hot-dip galvanised for masonry contact.
How do I size a lintel?
Lintel size depends on the opening width, the masonry load above and whether the wall is single-skin or cavity. Manufacturers' span tables cover standard cases; for anything unusual, an engineer should specify the section.
Why must lintels be galvanised?
Lintels sit in mortar and are exposed to moisture, so hot-dip galvanising to AS/NZS 4680 is required for durability. Black steel lintels rust and stain the brickwork within a few years.
