Parallel FlangeChannel (PFC)
Parallel flange channel (PFC) — hot-rolled steel channel for framing, edge beams, purlins and lintels.
Parallel flange channel (PFC), commonly called steel channel, is a hot-rolled C-shaped structural section used for edge beams, framing, purlins, lintels and bracing. We supply the full range of PFC from 75 PFC to 380 PFC in Grade 300 to AS/NZS 3679.1, with mill test certificates and full traceability. Cutting, drilling and surface treatment are available to your specifications.
Product Range
Full Size Range
Parallel flange channel from 75 PFC through to 380 PFC to suit framing and secondary structural members.
Grade 300 Structural Steel
Hot-rolled to AS/NZS 3679.1 in Grade 300 with verified mechanical properties and weldability.
Steel Channel Sizes & Properties
Dimensions, mass per metre and section properties available to support structural design.
Cut & Drilled to Spec
Cutting to length and hole drilling to your drawings at our partner facilities.
Surface Treatment
Shop primer, paint or hot-dip galvanising as specified for the application environment.
PFC (Parallel Flange Channel) Sizes
Standard Australian parallel flange channel sizes to AS/NZS 3679.1 in Grade 300.
| Designation | Depth (mm) | Flange width (mm) | Mass (kg/m) |
|---|---|---|---|
| 75 PFC | 75 | 40 | 5.92 |
| 100 PFC | 100 | 50 | 8.33 |
| 125 PFC | 125 | 65 | 11.9 |
| 150 PFC | 150 | 75 | 17.7 |
| 180 PFC | 180 | 75 | 20.9 |
| 200 PFC | 200 | 75 | 22.9 |
| 230 PFC | 230 | 75 | 25.1 |
| 250 PFC | 250 | 90 | 35.5 |
| 300 PFC | 300 | 90 | 40.1 |
| 380 PFC | 380 | 100 | 55.2 |
Additional sizes, grades, lengths and finishes available on request — contact us for a full size chart and quote.
Common Applications
- Edge beams and floor framing
- Purlins, girts and secondary framing
- Lintels over openings
- Bracing and connection members
- General structural fabrication
Relevant Standards
- AS/NZS 3679.1 — Hot-rolled structural steel bars and sections
- AS 4100 — Steel structures
- AS/NZS 1554 — Structural steel welding
