SHSSteel

Square hollow section (SHS) — steel square tube and box section for posts, columns, bollards, fencing and balustrades.

Square hollow section (SHS), also called steel square tube or steel box section, is cold-formed tube with four equal sides. Its strength is the same in both directions, which makes it the natural choice for anything that stands up: posts, columns, bollards, fence and gate posts, balustrade uprights and verandah supports. The range splits in two. Light SHS from 20 × 20 to 50 × 50 is bought by the length for gates, fencing, furniture, racking and frames; 40 × 40 and 50 × 50 are the most common sizes. Heavy structural SHS from 75 × 75 to 400 × 400 carries building, mezzanine and canopy loads as columns, usually with welded base and cap plates. We supply both to AS/NZS 1163 in Grade C350L0 and C450L0, black, pre-galvanised or hot-dip galvanised, in project and bulk quantities with mill test certificates.

Product Range

01

Steel Square Tube for Posts & Fencing

40 × 40, 50 × 50, 65 × 65 and 75 × 75 square tube for fence and gate posts, balustrade uprights, pergola and verandah posts, cut to post length.

02

Light Box Section (20 × 20 to 50 × 50)

Thin-wall steel box section from 1.6 mm for gates, frames, furniture, racking, trailers and shopfitting.

03

Structural SHS Columns

75 × 75 to 400 × 400 SHS in walls to 16 mm for building, mezzanine and canopy columns, sized to AS 4100.

04

Bollards & Barriers

100 × 100 to 150 × 150 heavy-wall SHS for vehicle bollards, barrier posts and impact protection, galvanised for outdoor use.

05

Pre-Galvanised & Hot-Dip Galvanised

In-line galvanised C450 square tube for light framing and fencing, or hot-dip galvanised SHS to AS/NZS 4792 for coastal and in-ground posts.

06

Posts Made Ready to Install

SHS posts and columns cut to length with welded base plates, cap plates and cleats, ready to bolt down.

SHS (Square Hollow Section) Sizes

Common Australian SHS and steel square tube sizes to AS/NZS 1163 in Grade C350L0 / C450L0, with the job each size usually does. Available black, pre-galvanised or hot-dip galvanised.

Size (mm)Wall thickness (mm)Typical use
20 × 201.6 – 2.0Furniture, shopfitting, light frames
25 × 251.6 – 3.0Gate infill, racking, light frames
35 × 351.6 – 3.0Gate frames, balustrade rails
40 × 401.6 – 4.0Gates, trailers, fence rails
50 × 501.6 – 5.0Fence and gate posts, frames
65 × 652.0 – 6.0Gate posts, pergola posts
75 × 752.0 – 6.0Carport and verandah posts
100 × 1002.0 – 9.0Columns, bollards, canopy posts
125 × 1254.0 – 9.0Building and mezzanine columns
150 × 1505.0 – 10.0Heavy columns, vehicle bollards
200 × 2005.0 – 12.5Primary building columns
400 × 40010.0 – 16.0Heavy structural columns

Additional sizes, grades, lengths and finishes available on request — contact us for a full size chart and quote.

Common Applications

  • Fence, gate and boundary posts
  • Building and mezzanine columns
  • Bollards and vehicle barriers
  • Balustrade and handrail uprights
  • Carport, verandah and pergola posts
  • Gates, furniture and light frames

Relevant Standards

  • AS/NZS 1163 — Cold-formed structural steel hollow sections
  • AS 4100 — Steel structures
  • AS/NZS 4792 — Hot-dip galvanized (zinc) coatings on ferrous hollow sections
  • AS/NZS 1554 — Structural steel welding

SHS Steel — Frequently Asked Questions

Is SHS the same as steel square tube or box section?

Yes. SHS (square hollow section), steel square tube and box section are the same product: cold-formed square steel tube made to AS/NZS 1163. Engineers say SHS; fabricators and fencers often say square tube or box section.

What size SHS is used for posts?

50 × 50 and 65 × 65 SHS are common for fence and gate posts, 75 × 75 to 100 × 100 for carport and verandah posts, and 100 × 100 to 150 × 150 heavy-wall SHS for bollards and building columns. Load, height and footing set the final size.

When should I use SHS instead of RHS?

SHS has the same strength in both directions, so it suits posts, columns and bollards that can be loaded from any side. RHS is stronger in one direction, so it suits beams, rafters and frame members that bend one way.
